KEY FEATURES:
• Superior brightness
• Narrow to wide zoom ranges (5°-84° total) in one unit
• Ground breaking new color mix system able to achieve CMY and RGB colors (CMY-s®, Patent Pending)
• Effects wheel for creating texture and aerial effects with wash light (Patent Pending)
• Electronically adjustable lamp power (700 W to 1450 W)
• Various lens options (zoom kit 6°-36° for extra brightness, PC lens for ACL type beam)
• Beam shaper rotating and indexing at 360° (Patent Pending)
SPECIFICATIONS:
• CMY-s® color mixing system with new saturation mode (Patent Pending)
• 5 colors + open
• 1 multicolor effect filter
• Proportional CTO filter
• 2 prismatic effects: moon flower, beam’o (Patent Pending)
• Beamshaper 360° (Patent Pending)
• Proportional zoom 5° - 84°
• Dimmer
• Mechanical and electronic strobe (zap effect), synchronized, random, pulse effect
• Modular design for easy maintenance and servicing
• Pan 538°, Tilt 252°, 16 bit
PHYSICAL SIZE:
• Length: 450 mm (17.7 in)
• Width: 450 mm (17.7 in)
• Height: 750 mm (29.5 in), head straight up
• Weight: 45 kg (99.2 lbs)
LAMP AND BALLAST:
• Type: Philips MSR Gold 1200 Fast Fit
• Color temperature: 6300 Kelvin
• Color rendering index: >80
• Average lamp life: 750 hours
• Socket: PGJX50
• Electronic ballast with Power Factor Correction
• Electronically adjustable lamp power (700 W to 1450 W), via DMX
CONTROL PROTOCOL AND PROGRAMMING:
• USITT DMX512/1990
• DMX channels: 22
• Setting and addressing: LCD display or remotely
ELECTRICAL SPECIFICATIONS/CONNECTIONS:
• AC power: 200-208/230/240 V, 50/60 Hz, 2m (6.6 ft) integral cable without power plug
• Power consumption: 8 A at 230 V
• DMX data in/out: 3 pin and 5 pin locking XLR
OPTIONS:
• PC Lens (# 9136)
• LD Zoom 5° - 36° kit (# 9136/1) |
