| | KEY FEATURES:
• a work horse, it does all you need but better than you expected
• 8°- 49° zoom
• Maximum exploitation of the new 1500 W light source
• Unique variety of effect generated
• superior dimming
• superior cmy
SPECIFICATIONS:
• CMY color mixing system
• 5 colors + open
• Proportional CTO
• 1 aerial wheel, 6 rotating gobos + open
• 1 break-up wheel, 6 rotating gobos + open
• 1 effect wheel, for rotating prisms and gobo effects, 6 + open
• Focus
• Proportional zoom 7°- 50°
• Iris
• Dimmer (mechanical and digital)
• Mechanical strobe, electronic strobe (zap effect), synchronized, random, pulse effect
• Modular design for easy maintenance and servicing
• Pan 530°, Tilt 270°, 16 bit
PHYSICAL SIZE:
• Length: 450 mm (17.7 in)
• Width: 505 mm (19.9 in)
• Height: 880 mm (30.7 in), head straight up
• Weight: 51 kg (112.4 lbs)
LAMP AND BALLAST:
• Type: Philips MSR Gold 1500 Fast Fit
• Color temperature: 6000 Kelvin
• Color rendering index: 83
• Average lamp life: 750 hours
• Socket: PGJX50
• Electronic ballast with Power Factor Correction
CONTROL PROTOCOL AND PROGRAMMING:
• USITT DMX512/1990
• Arnet
• DMX channels: 30
• Setting and addressing: LCD display or remotely
ELECTRICAL SPECIFICATIONS/CONNECTIONS:
• AC power: 190 - 250 V, auto-sensing, 50/60 Hz, 2m (6.6 ft) integral cable without power plug
• Power consumption: 8 A at 230 V
• DMX data in/out: 3 pin and 5 pin locking XLR
• Ethernet RJ45 port |
