KEY FEATURES: • Bright as a 575 W fixture, in a package half the size • Replace both 575 and 250 spot fixtures with one fully equipped moving light • Space, weight, power saving • Amazing zoom range from 35° down to 9° • Silent operation for the quietest applications • Iris and all other professional features • Rotating and indexing prism effects
SPECIFICATIONS: • CMY color mixing • 5 colors + open • CTO filter • 1 aerial wheel, 7 gobos + open • 1 break-up wheel, 7 gobos + open • 3 rotating prisms • Focus • Proportional zoom 9° - 35° • Iris • Dimmer • Mechanical and electronic strobe (zap effect), synchronized, random, pulse effect • Modular design for easy maintenance and servicing • Pan 540°, Tilt 284°, 16 bit
PHYSICAL SIZE: • Length: 459 mm (18.1 in) • Width: 377 mm (14.8 in) • Height: 602 mm (23.7 in), head straight up • Weight: 23.5 kg (51.8 lbs)
LAMP AND BALLAST: • Type: Philips MSR Gold 300/2 FastFit • Color temperature: 8000 Kelvin • Color rendering index: 75 • Average lamp life: 750 hours • Socket: PGJX28 • Electronic ballast with Power Factor Correction
CONTROL PROTOCOL AND PROGRAMMING: • USITT DMX512/1990 • Artnet • DMX channels: 23 • Setting and addressing: LCD display or remotely
ELECTRICAL SPECIFICATIONS/CONNECTIONS: • AC power: 90 – 250 V, auto sensing, 50/60 Hz, 2m (6.6 ft) integral cable without power plug • Power consumption: 2 A at 230 V, 4.4 A at 115 V • DMX data in/out: 3 pin and 5 pin locking XLR • Ethernet RJ45 port
