Fluid consumption 0.035 L (1.05 oz)(per minute at full output)
Liquid CO2 type Low pressure version: Low pressure refrigerated
Liquid CO2 consumption Low pressure version: 3 L (6.8 lb) at 1500 kPa (225 psi)(per minute) 1.5 L (3.4 lb) at 1500 kPa (225 psi)
High pressure version:1.35 kg (3 lb) at 6000 kPa (875 psi)
Reservoir capacity 2.5 L (0.66 US gallon)
Fog colour Pure white
Particle size 0.5-4.5 microns
CO2 running time Low pressure version: 180 L (48 US gallon)180 L (48 US gallon) canister (DEWAR) = 70 minutes canister (DEWAR) = 120 minutes
High pressure version: 23 kg (50 lb)
Warm-up time (maximum) 8 minutes
Fluid type MDG Low Fog Fluid (M.S.D.S. available on request)
Operating voltage 115 or 230 VAC, 50/60 Hz
Power consumption 1,450 W
Dimensions Total length 1.15 m (45 1/8“)
Operating length 1.08 m (42 3/8”)
Width 63.5 cm (25”)
Height 82.5 cm (32 1/2”)
Weight 91 kg (200 lb)
Approval CE approved, CSA CE approved, CSA and UL pending and UL pending
Remote control • 8 m (26 ft) 5-pin XLR extension cable • 2.5 m (8 ft) long x 13 cm (5 in) diameter fog output conduit 23 cm (9 in) diameter fog output conduit• 3 m (10 ft) insulated low-pressure liquid CO2 input hose with gauge
