 | KEY FEATURES:
• Brighter than a 575 W fixture, in a package half the size
• Replace both 575 and 250 wash fixtures with one fully equipped moving light
• Space, weight, power saving
• Effect engine
• Amazing zoom range from 24° down to 4°
• Moon flower aerial effect (Patent Pending)
• Zoom tight as an ACL
• Silent operation for the quietest applications
SPECIFICATIONS:
• CMY color mixing
• 5 colors + open
• CTO filter
• Beam shaper 360° (Patent Pending)
• 2 Prismatic effects: moon flower, beam‘o (Patent Pending)
• Proportional zoom 4° - 24°
• Dimmer
• Mechanical and electronic strobe (zap effect), synchronized, random, pulse effect
• Modular design for easy maintenance and servicing
• Pan 540°, Tilt 284°, 16 bit
PHYSICAL SIZE:
• Length: 459 mm (18.1 in)
• Width: 377 mm (14.8 in)
• Height: 602 mm (23.7 in), head straight up
• Weight: 23 kg (50.7 lbs)
LAMP AND BALLAST:
• Type: Philips MSR Gold 300/2 FastFit
• Color temperature: 8000 Kelvin
• Color rendering index: 75
• Average lamp life: 750 hours
• Socket: PGJX28
• Electronic ballast with Power Factor Correction
CONTROL PROTOCOL AND PROGRAMMING:
• USITT DMX512/1990
• Artnet
• DMX channels: 18
• Setting and addressing: LCD display or remotely
ELECTRICAL SPECIFICATIONS/CONNECTIONS:
• AC power: 90 – 250 V, auto sensing, 50/60 Hz,
2m (6.6 ft) integral cable without power plug
• Power consumption: 2 A at 230 V, 4.4 A at 115 V
• DMX data in/out: 3 pin and 5 pin locking XLR
• Ethernet RJ45 port |
